04015KA-24N-AL NMB 24V DC fan

Name: 04015KA-24N-AL NMB 24V DC fan
Brand: NMB
SKU: 899069383487
Availability: InStock
Rating: 5 (4 reviews)

$5.71

SKU: 899069383487 Brand: NMB

Description
Reviews (0)

Description

NMB Technologies 04015KA-24N-AL DC Axial Fan. This precision thermal management component utilizes MinebeaMitsumi’s advanced aerodynamic design to deliver consistent airflow in space-constrained industrial environments. The unit features a robust PBT housing and proprietary ball bearing system, ensuring longevity and stability in continuous-duty applications. Designed for 24V DC systems, this fan provides an optimal balance of static pressure and airflow, making it critical for maintaining thermal equilibrium in sensitive electronic assemblies.

Manufacturer: NMB Technologies (MinebeaMitsumi)
Model: 04015KA-24N-AL
Device Type: DC Axial Cooling Fan
Frame Dimensions: 40mm x 40mm x 15mm
Rated Voltage: 24V DC
Current: 0.08 A
Input Power: 1.92 W
Bearing Type: Dual Ball Bearing
Nominal Speed: 8000 RPM
Max Airflow: 0.23 m³/min (8.1 CFM)
Static Pressure: 58 Pa
Noise Level: 36.0 dB
Housing Material: Reinforced PBT (UL94V-0)
Impeller Material: Reinforced PBT (UL94V-0)
Operating Temperature: -10°C to +70°C
Life Expectancy: 60,000 Hours (at 25°C)
Termination: Lead Wire
Weight: 25g

Application Analysis:
This specific model is engineered for high-impedance airflow paths found in compact server chassis, industrial power supply units, and dense radiator configurations. Its high static pressure capability allows it to effectively push air through restrictive fins and heatsinks where standard fans fail, preventing thermal throttling in mission-critical hardware.

Procurement Data:
Item condition is New and Unused in original packaging. Sourcing Original Engineering guarantees adherence to specified MTBF and noise curves. Verify Technical Compatibility with your specific voltage bus and dimensional constraints prior to integration. Immediate availability minimizes Lead Time for urgent maintenance requirements.

04015KA-24N-AL NMB 24V DC fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
