4658N ebmpapst 120x120x38mm 230V AC Cabinet Axial Fan

Name: 4658N ebmpapst 120x120x38mm 230V AC Cabinet Axial Fan
Brand: ebmpapst
SKU: 1600825514041
Availability: InStock
Rating: 5 (4 reviews)

$18.50

SKU: 1600825514041 Brand: ebmpapst

Description
Reviews (0)

Description

The ebmpapst 4658N represents the benchmark in Original Engineering for high-performance thermal management. This AC axial fan is designed for industrial applications requiring robust Technical Compatibility and long-term reliability in demanding environments. Its full metal construction ensures structural integrity at elevated temperatures, providing a significant advantage over composite alternatives.

Technical Specifications:
Manufacturer: ebmpapst
Model Number: 4658N
Product Type: AC Axial Fan
Nominal Voltage: 230 VAC
Frequency: 50/60 Hz
Power Consumption: 19.0 W
Speed: 2650 RPM
Air Flow: 160 m³/h
Air Flow: 94.2 CFM
Sound Pressure Level: 46 dB(A)
Sound Power Level: 5.4 B
Ambient Temperature Range: -40 °C to +75 °C
Service Life L10 at 40 °C: 37500 h
Service Life L10 at 75 °C: 15000 h
Bearing Type: Ball Bearing
Direction of Rotation: Clockwise (viewed toward rotor)
Direction of Air Flow: Exhaust over struts
Housing Material: Die-cast aluminum
Impeller Material: Sheet steel, painted black
Motor Protection: Impedance protected
Electrical Connection: 2 flat plugs 2.8 x 0.5 mm
Dimensions: 120 x 120 x 38 mm
Weight: 0.550 kg
Approval Certifications: VDE, CSA, UL, CE
Origin: Germany

Industrial Application:
The 4658N is specifically utilized in high-density power electronics and industrial control cabinets where heat dissipation is critical to preventing system downtime. Its ability to operate at +75 °C makes it indispensable for localized cooling in smelting control systems, telecommunications infrastructure, and heavy-duty CNC machinery. By maintaining consistent airflow under high static pressure, it ensures the longevity of sensitive electronic components. Optimized logistics ensure a competitive Lead Time for global MRO requirements.

Key Attributes
Voltage: 230V
Mounting type: Free Standing
Type: Axial Cooling Fan
Warranty: 1 Year
Power Source: Electric
Blade material: Metal
Bearing type: Ball Bearing
Customized support: OEM
After-sales service provided: Online support
Place of origin: Germany
Brand name: Ebmpapst
Model number: 4658N
Type: Axial Fan
Nominal voltage: 230 V
Bearing Type: Ball Bearing
Power consumption: 19W
Speed Control: 2650RPM
Frequency: 50~60Hz
Air Flow: 94.2cfm
Bearings: Ball Bearing
Size: 120*120*38mm
Weight: 550g

Packaging and Delivery
Selling Units: Single item

4658N ebmpapst 120x120x38mm 230V AC Cabinet Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
