AS12048UB25AB00 ADDA DC brushless fan

Name: AS12048UB25AB00 ADDA DC brushless fan
Brand: ADDA
SKU: 898124306146
Availability: InStock
Rating: 5 (4 reviews)

$4.00

SKU: 898124306146 Brand: ADDA

Description
Reviews (0)

Description

The ADDA AS12048UB25AB00 is a high-performance DC brushless axial fan engineered for rigorous industrial thermal management and telecommunications infrastructure. This unit features Original Engineering from ADDA Corporation, specifically calibrated for 48V DC power backplanes. The fan utilizes a precision dual ball bearing system to ensure mechanical stability and extended service life under continuous high-speed operation. Its 120mm form factor with a standard 25mm depth ensures Technical Compatibility with legacy rack-mount chassis and ventilation arrays. The unit delivers a high airflow-to-noise ratio, making it suitable for environments requiring efficient heat dissipation without compromising system reliability.

Manufacturer: ADDA Corporation
Model Number: AS12048UB25AB00
Component Type: DC Brushless Axial Fan
Frame Dimensions: 120 mm x 120 mm x 25 mm
Rated Voltage: 48V DC
Operating Voltage Range: 28V – 56V DC
Rated Current: 0.46 A
Input Power: 22.08 W
Speed Class: Ultra High Speed (U Series)
Nominal Speed: 3800 RPM ±10%
Max Airflow: 150.0 CFM (Approximate)
Static Pressure: 0.55 In H2O
Noise Level: 53.0 dB(A)
Bearing System: Dual Ball Bearing
Housing Material: PBT Thermoplastic (UL94V-0)
Impeller Material: PBT Thermoplastic (UL94V-0)
Operating Temperature: -10°C to +70°C
Life Expectancy: 70,000 Hours at 40°C
Termination: Lead Wire Assembly
Certifications: UL, cUL, TUV, CE

Industrial Application:
This specific 48V DC fan is optimized for high-impedance airflow requirements within telecommunications base stations, rectifiers, and high-density server racks where 48V DC is the standard bus voltage. The 0.46A current draw indicates a high-torque motor capable of sustaining critical airflow against the significant back-pressure found in densely packed electronic enclosures. It serves as a critical component for preventing thermal throttling in network switches and power inverters. Contact us to confirm current Lead Time for maintenance spares or OEM integration.

AS12048UB25AB00 ADDA DC brushless fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
