D4E225-CC01-02 ebmpapst Fan Centrifugal Fan ebmpapst TYPE:D4E225-CC01-02 AC 230V

D4E225-CC01-02 ebmpapst Fan Centrifugal Fan ebmpapst TYPE:D4E225-CC01-02 AC 230V

Name: D4E225-CC01-02 ebmpapst Fan Centrifugal Fan ebmpapst TYPE:D4E225-CC01-02 AC 230V
Brand: ebmpapst
SKU: 60839359304
Availability: InStock
Rating: 5 (4 reviews)

$459.00

SKU: 60839359304 Brand: ebmpapst

Description
Reviews (0)

Description

The Ebmpapst D4E225-CC01-02 is a precision-engineered dual-inlet centrifugal blower featuring the M4E074-LA external rotor motor, designed for high-efficiency air movement in industrial HVAC applications. This unit utilizes forward-curved impeller geometry housed within a robust hot-galvanized sheet steel scroll, ensuring durability and corrosion resistance in demanding environments. The 4-pole single-phase motor configuration delivers reliable torque with optimized acoustic characteristics, making it suitable for noise-sensitive ventilation systems. Original Engineering specifications ensure seamless integration with existing control infrastructure, maintaining system integrity and airflow performance curves. The ball bearing system supports continuous duty cycles, reducing maintenance intervals and extending the operational lifecycle.

TECHNICAL SPECIFICATIONS
Manufacturer: ebm-papst
Model Reference: D4E225-CC01-02
Motor Designation: M4E074-LA
Product Type: Dual Inlet Centrifugal Blower
Impeller Design: Forward Curved
Nominal Voltage: 230 V AC
Frequency: 50 / 60 Hz
Phase: 1~ (Single Phase)
Impeller Diameter: 225 mm
Housing Material: Sheet steel, hot-galvanized
Impeller Material: Sheet steel, hot-galvanized
Bearing Type: Maintenance-free Ball Bearings
Motor Protection: Thermal Overload Protector (TOP) wired internally
Mounting Orientation: Any (Shaft horizontal or vertical)
Gross Weight: 13.00 kg
Package Dimensions: 45 x 45 x 45 cm
Insulation Class: B
Protection Class: IP44
Capacitor Operation: Required for functionality

INDUSTRIAL APPLICATION
This centrifugal blower is specifically engineered for Air Handling Units (AHUs), Variable Air Volume (VAV) boxes, and electronic cabinet cooling systems where high static pressure generation is required within a compact footprint. The D4E225-CC01-02 provides critical thermal management and air exchange in cleanroom filtration setups, ensuring consistent airflow against filter resistance. We verify Technical Compatibility for replacement scenarios to minimize downtime. Contact us for current Lead Time and shipping logistics.

Mounting: Any
Voltage: 230V
Blade Material: Sheet steel, hot-galvanised
Warranty: 1 Year
After-sales Service Provided: Online support
Place of origin: Germany
Brand name: Ebmpapst
Motor: M4E074-LA
Size: 225 mm
Bearing Type: Ball bearing
Frequency: 50/60 HZ
Feature: Low Noise Power Saving
Type: Centrifugal Fan
Selling Units: Single item
Single package size: 45X45X45 cm
Single gross weight: 13.000 kg

D4E225-CC01-02 ebmpapst Fan Centrifugal Fan ebmpapst TYPE:D4E225-CC01-02 AC 230V

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
