Delta’s AFB0812SHB fan 80x80x15mm

Name: Delta’s AFB0812SHB fan 80x80x15mm
Brand: Delta
SKU: 918155358372
Availability: InStock
Rating: 5 (4 reviews)

$3.14

SKU: 918155358372 Brand: Delta

Description
Reviews (0)

Description

The Delta Electronics AFB0812SHB is a high-performance DC axial fan engineered for critical thermal management in compact industrial enclosures and high-density computing environments. This unit features Original Engineering design utilizing a precision dual ball bearing system, ensuring extended operational lifecycle and superior axial load stability compared to standard sleeve bearing alternatives. With a specific 15 mm slim profile, this model addresses spatial constraints in rack-mount servers, 1U/2U chassis, and industrial power supply units while maintaining high static pressure capabilities required to overcome system impedance. The 12V DC motor is calibrated for high-speed operation, delivering substantial airflow to dissipate heat from CPUs and sensitive electronic components efficiently. Technical Compatibility is verified for standard industrial headers, facilitating seamless integration into existing thermal loops. Current Lead Time for this specific configuration supports immediate maintenance and retrofit requirements.

Manufacturer: Delta Electronics
Model Number: AFB0812SHB
Component Type: DC Axial Cooling Fan
Dimensions: 80 mm x 80 mm x 15 mm
Rated Voltage: 12 VDC
Operating Voltage Range: 7.0 VDC to 13.8 VDC
Rated Current: 0.40 A
Input Power: 4.80 W
Rotational Speed: 4000 RPM ±10%
Maximum Airflow: 1.32 m³/min (46.6 CFM)
Static Pressure: 6.5 mmH2O
Acoustic Noise: 43.0 dB-A
Bearing Type: Dual Ball Bearing
Life Expectancy: 70,000 Hours at 40°C
Housing Material: PBT Plastic (UL 94V-0)
Impeller Material: PBT Plastic (UL 94V-0)
Operating Temperature: -10°C to +70°C
Safety Certifications: UL, CSA, VDE, CE
Weight: 62 g

Delta’s AFB0812SHB fan 80x80x15mm

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
