Name: ebm-papst S4D350-BP08-31 M4D074-DF 230VAC 350mm Axial Cooling Fan
Brand: ebmpapst
SKU: 1600842976681
Availability: InStock
Rating: 5 (4 reviews)

$159.00

SKU: 1600842976681 Brand: ebmpapst

Description
Reviews (0)

Description

The ebm-papst S4D350-BP08-31 is a high-performance axial fan engineered for industrial refrigeration and ventilation systems requiring high-density airflow and thermal stability. Built on the M4D074-DF motor platform, this unit represents Original Engineering standards, ensuring seamless Technical Compatibility with commercial condensers and heat exchangers. The assembly features a 350 mm diameter impeller with five blades constructed from black-coated sheet steel, optimized for aerodynamic efficiency and low noise emission.

Technical Specifications:
Brand: ebm-papst
Model Number: S4D350-BP08-31
Motor Model: M4D074-DF
Nominal Voltage: 230 VAC
Phase: 3~
Frequency: 50/60 Hz
Power Consumption: 130 W
Current Draw: 0.61 A
Speed: 1410 RPM
Airflow Capacity: 3280 m³/h
Impeller Diameter: 350 mm
Number of Blades: 5
Blade Material: Sheet steel, coated in black
Degree of Protection: IP44
Insulation Class: B
Bearing Type: Maintenance-free ball bearings
Operating Temperature Range: -25 °C to +60 °C
Weight: 4.7 kg
Origin: Germany
Compliance: CE, VDE
Mounting Position: Any
Mode of Operation: S1 (Continuous operation)

Application:
This fan is specifically utilized in large-scale evaporator units and cooling towers where consistent static pressure and reliable Lead Time are essential for maintaining cold chain integrity. The robust ball bearing system is designed for continuous duty cycles, minimizing maintenance intervals in critical infrastructure applications.

Key Attributes
Voltage: 230V
Mounting type: Free Standing
Type: Axial Cooling Fan
Warranty: 1 Year
Power Source: Electric
Blade material: Sheet steel, coated in black
Bearing type: Ball Bearing
Customized support: OEM
After-sales service provided: Online support
Place of origin: Germany
Brand name: Ebmpapst
Model number: S4D350-BP08-31
Nominal voltage: 230V
Bearing Type: Ball Bearing
Power consumption: 130W
Speed: 1410RPM
Current: 0.61A
Frequency: 50~60Hz
Weight: 4.7KG
Size: 350MM
Number of blades: 5
Insulation class: B

Packaging and Delivery
Selling Units: Single item

ebm-papst S4D350-BP08-31 M4D074-DF 230VAC 350mm Axial Cooling Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
