ebmpapst 8550VW 230VAC 12W 80mm Cabinet Axial Fan

Name: ebmpapst 8550VW 230VAC 12W 80mm Cabinet Axial Fan
Brand: ebmpapst
SKU: 1600828829918
Availability: InStock
Rating: 5 (4 reviews)

$19.00

SKU: 1600828829918 Brand: ebmpapst

Description
Reviews (0)

Description

Manufacturer: ebmpapst
Model Number: 8550VW
Product Category: AC Axial Compact Fan
Nominal Voltage: 230 VAC
Frequency: 50/60 Hz
Power Consumption: 12.0 W
Air Flow: 50.0 m³/h (29.4 CFM)
Rotational Speed: 3200 RPM
Sound Pressure Level: 35 dB(A)
Sound Power Level: 4.8 B(A)
Housing Material: Die-cast aluminum
Impeller Material: Fiberglass-reinforced PA plastic
Bearing Type: Sintec sleeve bearing system
Electrical Connection: 2 single strands AWG 22, TR 64
Direction of Rotation: Clockwise, viewed toward rotor
Direction of Airflow: Exhaust over struts
Dimensions: 80 x 80 x 38 mm
Weight: 0.490 kg
Ingress Protection: IP20
Operating Temperature Range: -10 °C to +70 °C
Service Life L10 at 40 °C: 52500 h
Service Life L10 at Max Temp: 25000 h
Approvals: VDE, CSA, UL, CE
Motor Type: Shaded pole motor
Technical Compatibility: Standard 80mm industrial mounting patterns
Original Engineering: German precision thermal management
Application: The ebmpapst 8550VW is engineered for high-density thermal management in compact industrial enclosures. Its 38mm depth allows for superior static pressure development compared to standard 25mm variants, making it the optimal choice for cooling power supplies, control cabinets, and telecommunications racks where airflow resistance is high. The Sintec sleeve bearing system ensures quiet operation and long-term reliability in fixed-position industrial installations. This component is critical for maintaining stable operating temperatures in sensitive electronic environments, preventing thermal throttling and hardware failure. Lead Time: Available for immediate dispatch with global logistics support.

Key Attributes
Voltage: 230V
Mounting type: Free Standing
Type: Axial Cooling Fan
Warranty: 1 Year
Power Source: Electric
Blade material: Plastic
Bearing type: Sleeve Bearing
Customized support: OEM
After-sales service provided: Online support
Place of origin: Germany
Brand name: Ebmpapst
Model number: 8550VW
Size: 80*80*38mm
Nominal voltage: 230V
Power: 12W
Air flow: 29.4CFM
Bearing Type: Sleeve Bearing
Frequency: 50~60Hz
Speed Control: 3200 RPM
Housing Material: Metal
IP Rating: IP20
Weight: IP20

Packaging and Delivery
Selling Units: Single item

ebmpapst 8550VW 230VAC 12W 80mm Cabinet Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
