ebmpapst A2D210-AA10-17 400V AC 130W 3250RPM 210mm Siemens 1PH713 Series Spindle Servo Motor Axial Fan

ebmpapst A2D210-AA10-17 400V AC 130W 3250RPM 210mm Siemens 1PH713 Series Spindle Servo Motor Axial Fan

Name: ebmpapst A2D210-AA10-17 400V AC 130W 3250RPM 210mm Siemens 1PH713 Series Spindle Servo Motor Axial Fan
Brand: ebmpapst
SKU: 62043009672
Availability: InStock
Rating: 5 (4 reviews)

$160.00

SKU: 62043009672 Brand: ebmpapst, Siemens

Description
Reviews (0)

Description

The ebm-papst A2D210-AA10-17 is a precision-engineered 3-phase axial fan module designed explicitly for the forced ventilation of Siemens 1PH713 series main spindle servo motors. This unit represents Original Engineering quality, ensuring exact aerodynamic performance required to dissipate heat generated during high-dynamic machining operations. Unlike generic replacements, this fan maintains the specific pressure curve necessary to prevent thermal derating of the servo system. The assembly features a robust 2-pole external rotor motor integrated directly into the impeller hub, optimizing the axial depth for compact motor cowlings. Technical Compatibility is guaranteed for Siemens drive systems requiring 400V 3-phase cooling solutions, ensuring seamless integration with existing machine tool interfaces. We prioritize supply chain efficiency to offer a reduced Lead Time for critical maintenance requirements.

Manufacturer: ebm-papst
Model Reference: A2D210-AA10-17
Application: Siemens 1PH713 Spindle Servo Motor Cooling
Fan Type: AC Axial Fan
Motor Technology: AC External Rotor (3-Phase)
Nominal Voltage: 400 V
Frequency: 50 / 60 Hz
Power Consumption: 130 W
Nominal Speed: 3250 RPM
Current Draw: 0.25 A / 0.27 A
Impeller Diameter: 210 mm
Impeller Material: Sheet Steel (Black Coated)
Bearing Type: Maintenance-Free Ball Bearings
Motor Size: 68
Direction of Rotation: Counter-clockwise (viewed on rotor)
Insulation Class: F
Protection Rating: IP44
Net Weight: 1.7 kg
Mounting Configuration: Siemens Specific Flange/Housing
Phase: 3-Phase

Key Attributes
Voltage: 400V
Mounting type: Free Standing
Type: Ac axial fan
Warranty: 1 Year
Power Source: Electric
Blade material: Cast Iron
Bearing type: Ball Bearing
Customized support: OEM, ODM
After-sales service provided: Online support
Place of origin: Germany
Brand name: Ebmpapst
Model number: A2D210-AA10-17
Product name: Ebmpapst EC centrifugal fan - RadiCal
Nominal voltage: 400V
Bearing Type: Ball Bearing
Power consumption: 130W
Current: 0.25/0.27 A
Frequency: 50~60Hz
Fan Size: 210MM
Speed Control: 3250 (r/min)
Motor size: 68
Weigh: 1.7 kg

Packaging and Delivery
Selling Units: Single item
Single package size: 37X37X25 cm
Single gross weight: 4.000 kg

ebmpapst A2D210-AA10-17 400V AC 130W 3250RPM 210mm Siemens 1PH713 Series Spindle Servo Motor Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
