ebmpapst A4E350-AP06-30/A01 230V AC 350mm 1400RPM 130/190W Outer Rotor Cold Storage Axial Fan

ebmpapst A4E350-AP06-30/A01 230V AC 350mm 1400RPM 130/190W Outer Rotor Cold Storage Axial Fan

Name: ebmpapst A4E350-AP06-30/A01 230V AC 350mm 1400RPM 130/190W Outer Rotor Cold Storage Axial Fan
Brand: ebmpapst
SKU: 62052408785
Availability: InStock
Rating: 5 (4 reviews)

$118.50

SKU: 62052408785 Brand: ebmpapst

Description
Reviews (0)

Description

The ebmpapst A4E350-AP06-30/A01 is a high-performance axial fan engineered for demanding industrial cooling and ventilation applications. Manufactured in Germany, this unit features a 350mm diameter and utilizes a robust outer rotor motor design, which ensures a compact footprint and efficient heat dissipation. The fan blades are constructed from cast iron, providing exceptional structural integrity and resistance to deformation under high-pressure conditions.

Operating at a nominal voltage of 230 VAC, the A4E350-AP06-30/A01 delivers a rotational speed of 1400 RPM with a power consumption range of 130 – 190 W. The integration of high-quality ball bearings facilitates long-term maintenance-free operation and allows for installation in any orientation. With an IP44 protection rating, this fan is specifically designed to withstand moisture and dust ingress, making it an ideal solution for cold storage facilities, refrigeration units, and HVAC systems.

Technical Specifications:
Brand: ebmpapst
Model Number: A4E350-AP06-30/A01
Nominal Voltage: 230 VAC
Frequency: 50/60 Hz
Power Consumption: 130 – 190 W
Current Draw: 0.58 A
Fan Diameter: 350 mm
Speed: 1400 RPM
Bearing Type: Ball Bearing
Blade Material: Cast Iron
Protection Class: IP44
Weight: 10.00 kg
Origin: Germany

Industrial Application:
This axial fan is critical for thermal management in commercial refrigeration, evaporator units, and industrial heat exchangers. Its original engineering ensures reliable airflow in environments where consistent temperature control is vital for operational safety and product preservation. For procurement teams, this model offers a proven lead time advantage and compatibility with standard industrial mounting configurations.

Key Attributes
Voltage: 230V
Mounting type: Free Standing
Type: Ac axial fan
Warranty: 1 Year
Power Source: Electric
Blade material: Cast Iron
Bearing type: Ball Bearing
Customized support: OEM, ODM
After-sales service provided: Online support
Place of origin: Germany
Brand name: Ebmpapst
Model number: A4E350-AP06-30/A01
Type: Axial fan
Nominal voltage: 230(V)
Bearing Type: Ball Bearing
Power consumption: 130/190 (w)
Current: 0.58(A)
Fan Size: 350mm
Speed: 1400 r/min
Insulation Grade: IP44

Packaging and Delivery
Selling Units: Single item
Single package size: 47X47X34 cm
Single gross weight: 10.000 kg

ebmpapst A4E350-AP06-30/A01 230V AC 350mm 1400RPM 130/190W Outer Rotor Cold Storage Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
