Name: ebmpapst K2E200-AH20-05 230V AC 200mm 2700RPM Axial Cooling Fan
Brand: ebmpapst
SKU: 62005769045
Availability: InStock
Rating: 5 (4 reviews)

$195.00

SKU: 62005769045 Brand: ebmpapst

Description
Reviews (0)

Description

The ebmpapst K2E200-AH20-05 is a high-efficiency AC axial fan engineered for demanding thermal management applications within industrial automation and electronics cooling systems. Manufactured in Germany, this unit features an external rotor motor design that integrates the motor directly into the impeller hub, resulting in a compact depth profile ideal for space-constrained installations. It serves as a reliable industrial automation solution, often utilized as a direct replacement for cooling fans within Rittal cabinet filter units and other standard electrical enclosures. The fan is designed to maintain optimal operating temperatures for sensitive components by delivering consistent high-volume airflow.

Technically, the unit operates on a nominal voltage of 230V AC. It is driven by a size 68 motor equipped with a maintenance-free ball bearing system, which ensures long service life and stable operation regardless of the mounting orientation. The 200mm diameter impeller is constructed from durable, lightweight plastic, which reduces rotational inertia and mechanical stress on the motor. Operating at a speed of 2700 RPM, the fan achieves a substantial airflow of 600 m³/h while consuming 70W of power. The current draw is rated at 0.37A. This balance of speed and torque allows the K2E200-AH20-05 to overcome the static pressure resistance typically found in filtered cabinet intake systems.

The acoustic noise level is rated at 61 dBA, making it suitable for industrial environments where noise pollution must be managed. The unit is designed for continuous duty and provides pin-to-pin compatibility with existing setups requiring these specific aerodynamic and electrical parameters. Proper thermal dissipation provided by this fan helps prevent overheating in control panels, thereby reducing downtime in automated processes.

Technical Specifications
Brand: ebmpapst
Model: K2E200-AH20-05
Type: AC Axial Fan
Nominal Voltage: 230V AC
Frequency: 50 – 60 Hz
Impeller Diameter: 200mm
Rated Speed: 2700 RPM
Max Airflow: 600 m³/h
Power Consumption: 70W
Current: 0.37A
Noise Level: 61 dBA
Bearing Type: Ball Bearing
Motor Size: 68
Impeller Material: Plastic

This cooling fan is widely applied in electrical control cabinets for CNC machinery, variable frequency drive (VFD) ventilation systems, and server rack cooling modules. It is also used in medical equipment cooling and general industrial ventilation where reliable air movement is critical for system integrity.

Key Attributes
Voltage: 230 (V)
Mounting type: Free Standing
Type: Axial Cooling Fan
Warranty: 1 Year
Power Source: Electric
Blade material: Plastic
Bearing type: Ball Bearing
Customized support: OEM, ODM
After-sales service provided: Online support
Place of origin: Germany
Brand name: Ebmpapst
Model number: K2E200-AH20-05
Type: Axial Fan
Nominal voltage: 230V
Bearing Type: Ball Bearing
Power consumption: 70(w)
Speed: 2700 (r/min)
Current: 0.37(A)
Blade diameter: 200mm
Motor size: 68
Motor mounting: Ball bearing
Noise: 61dBA

Packaging and Delivery
Selling Units: Single item

ebmpapst K2E200-AH20-05 230V AC 200mm 2700RPM Axial Cooling Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
