Ebmpapst S3G450-LL07-M7 400V 530W EC Axial Fan

Ebmpapst S3G450-LL07-M7 400V 530W EC Axial Fan

Name: Ebmpapst S3G450-LL07-M7 400V 530W EC Axial Fan
Brand: ebmpapst
SKU: 1601211069697
Availability: InStock
Rating: 5 (4 reviews)

$834.00

SKU: 1601211069697 Brand: ebmpapst

Description
Reviews (0)

Description

The Ebmpapst S3G450-LL07-M7 is a high-performance EC axial fan engineered for precision thermal regulation in industrial environments. Utilizing GreenTech EC technology, this unit provides superior energy efficiency compared to conventional AC motors, making it an ideal solution for continuous operation in electric control cabinets and large-scale cooling systems. The fan features a robust construction with five blades manufactured from sheet steel, ensuring structural integrity and consistent aerodynamic performance under varying pressure conditions.

Technical Specifications:
Brand: Ebmpapst
Model Number: S3G450-LL07-M7
Motor Type: EC motor
Nominal Voltage: 400 VAC
Voltage Range: 380 – 480 VAC
Frequency: 50/60 Hz
Power Consumption: 530 W
Current Draw: 0.85 A
Speed: 1520 rpm
Max Air Flow: 4505 m³/h
Bearing Type: Maintenance-free ball bearings
Blade Material: Sheet steel, painted black
Number of Blades: 5
Direction of Rotation: Clockwise, viewed toward rotor
Degree of Protection: IP54
Insulation Class: F
Operating Temperature: -25 °C to +60 °C
Weight: 7.6 kg
Origin: Germany

Industrial Application:
This model is specifically designed for integration into electric control cabinets, frequency converters, and heat exchangers. Its high airflow capacity of 4505 m³/h ensures rapid heat dissipation, protecting sensitive electronic components from thermal overload. The integrated EC controller allows for seamless speed adjustment, optimizing energy consumption based on real-time cooling requirements.

Logistics and Quality:
As an original engineering component from Ebmpapst Germany, the S3G450-LL07-M7 meets rigorous European quality standards. Lead times are optimized for industrial procurement cycles. Each unit is supplied as a single item with a gross weight of 7.6 kg, ensuring secure transit for critical infrastructure projects.

Key Attributes
Voltage: 400V
Electric current type: AC
Mounting type: Free Standing
Warranty: 1 Year
Blade material: Sheet steel
Customized support: OEM, ODM
After-sales service provided: Online support
Place of origin: Germany
Brand name: Ebmpapst
Model number: S3G450-LL07-M7
Voltage: 400V
Bearing Type: Ball Bearing
Power: 530W
Current: 0.85A
Speed: 1520rpm
Air flow: 4505m³/h

Packaging and Delivery
Selling Units: Single item
Single package size: 53X53X21.5 cm
Single gross weight: 7.600 kg

Ebmpapst S3G450-LL07-M7 400V 530W EC Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
