ebmpapst S6E450-AP02-01 450mm 230VAC 165W Axial Fan

ebmpapst S6E450-AP02-01 450mm 230VAC 165W Axial Fan

Name: ebmpapst S6E450-AP02-01 450mm 230VAC 165W Axial Fan
Brand: ebmpapst
SKU: 1600838528924
Availability: InStock
Rating: 5 (4 reviews)

$239.00

SKU: 1600838528924 Brand: ebmpapst

Description
Reviews (0)

Description

The ebmpapst S6E450-AP02-01 is a high-performance axial fan featuring an AC external rotor motor designed for continuous operation in demanding thermal management systems. This unit utilizes Original Engineering to ensure optimal airflow-to-noise ratios in precision air conditioning and condenser applications.

Technical Specifications:
Manufacturer: ebmpapst
Model Number: S6E450-AP02-01
Motor Type: S6E (6-pole single-phase AC)
Nominal Voltage: 230 VAC
Frequency: 50/60 Hz
Power Consumption: 165 W
Current Rating: 0.8 A
Rotational Speed: 940 RPM
Impeller Diameter: 450 mm
Number of Blades: 3
Blade Material: Glass-fiber reinforced plastic (PA)
Bearing Type: Maintenance-free ball bearings
Degree of Protection: IP44
Insulation Class: F
Operating Temperature: -25°C to +60°C
Direction of Rotation: Counter-clockwise (viewed toward rotor)
Direction of Airflow: V (Exhaust over struts)
Weight: 6.5 kg
Certifications: CE, VDE, EAC
Technical Compatibility: Industrial condensers, precision HVAC units, heat exchangers

Industrial Application:
The S6E450-AP02-01 is specifically utilized in precision air conditioning units where stable thermal regulation and low vibration are critical. The 6-pole motor configuration allows for a reduced speed of 940 RPM, making it ideal for noise-sensitive environments without compromising the static pressure required for dense condenser coils. Its robust IP44 protection and wide operating temperature range ensure long-term reliability in outdoor installations. Global lead time varies by region; contact for current availability.

Key Attributes
Voltage: 230V
Mounting type: Free Standing
Type: Axial Cooling Fan
Warranty: 1 Year
Power Source: Electric
Blade material: Plastic
Bearing type: Ball Bearing
Customized support: OEM
After-sales service provided: Online support
Place of origin: Germany
Brand name: Ebmpapst
Model number: S6E450-AP02-01
Type: Axial fan
Nominal voltage: 230(V)
Bearing Type: Ball Bearing
Power consumption: 165W
Speed: 940RPM
Current: 0.8A
Fan Size: 450 mm
Number of blades: 3
Type of protection: IP 44
Ambient temperature: -25°C-+60℃

Packaging and Delivery
Selling Units: Single item

ebmpapst S6E450-AP02-01 450mm 230VAC 165W Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
