Ebmpapst W2S130-AA13-87 110V AC 130mm Cabinet Axial Fan

Ebmpapst W2S130-AA13-87 110V AC 130mm Cabinet Axial Fan

Name: Ebmpapst W2S130-AA13-87 110V AC 130mm Cabinet Axial Fan
Brand: ebmpapst
SKU: 1600209722024
Availability: InStock
Rating: 5 (4 reviews)

$202.50

SKU: 1600209722024 Brand: ebmpapst

Description
Reviews (0)

Description

The Ebm-papst W2S130-AA13-87 is a high-performance AC axial fan engineered for precision thermal management in industrial environments. This unit utilizes the M2S052-CA shaded-pole motor, characterized by its external rotor design which provides compact dimensions and efficient cooling. Designed for continuous operation, the fan features a robust die-cast aluminum housing and seven stainless steel blades to ensure structural integrity under high aerodynamic loads. This model is specifically optimized for integration into UPS systems, control cabinets, and frequency converters where Technical Compatibility with 115V AC power grids is essential. The maintenance-free ball bearing system and impedance protection ensure long-term reliability and Original Engineering standards, minimizing Lead Time for maintenance cycles in critical infrastructure.

Technical Specifications:
Brand: Ebm-papst
Model Number: W2S130-AA13-87
Motor Model: M2S052-CA
Phase: 1~
Nominal Voltage: 115 VAC
Frequency: 50 / 60 Hz
Speed: 2800 / 3250 RPM
Power Consumption: 47 / 42 W
Current Draw: 0.72 / 0.55 A
Airflow: 325 / 380 m³/h
Static Pressure: 80 / 120 Pa
Blade Material: Stainless steel
Housing Material: Die-cast aluminum, coated in black
Bearing Type: Ball Bearing
Number of Blades: 7
Direction of Rotation: Counter-clockwise viewed toward rotor
Direction of Airflow: Exhaust over struts
Electrical Connection: 2 flat plugs 2.8 x 0.5 mm
Motor Protection: Impedance protected
Insulation Class: B
Degree of Protection: IP20
Operating Temperature Range: -25 °C to +70 °C
Weight: 1.1 kg
Fan Diameter: 130 mm
Dimensions: 150 x 172 x 38 mm
Approvals: VDE, CSA, UL, CE
Place of Origin: Germany

Industrial Application Scenario:
The W2S130-AA13-87 is primarily deployed in high-density electronic enclosures such as Uninterruptible Power Supplies (UPS) and industrial control cabinets. In these scenarios, the fan’s ability to maintain high static pressure against internal component resistance is critical for preventing thermal throttling. The stainless steel blade construction prevents deformation in high-temperature zones, ensuring consistent airflow logic and protecting sensitive semiconductor components from heat-induced failure.

Key Attributes
Voltage: 110V
Mounting type: Free Standing
Type: Axial Cooling Fan
Warranty: 1 Year
Power Source: Electric
Blade material: Stainless Steel
Bearing type: Ball Bearing
Customized support: OEM
After-sales service provided: Online support
Place of origin: Germany
Brand name: Ebm-papst
Model number: W2S130-AA13-87
Motor: M2S052-CA
Phase: 1~
Nominal voltage: 110VAC
Speed (rpm): 2800/3250
Power consumption: 47W/42W
Current draw: 0.72A/0.55A
Weight: 1.1 kg
Fan size: 130 mm
Number of blades: 7

Packaging and Delivery
Selling Units: Single item
Single package size: 21X21X11 cm
Single gross weight: 0.700 kg

Ebmpapst W2S130-AA13-87 110V AC 130mm Cabinet Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
