Name: G2E120-AR77-01 ebmpapst turbo Centrifugal fan
Brand: ebmpapst
SKU: 676311112754
Availability: InStock
Rating: 5 (4 reviews)

$94.29

SKU: 676311112754 Brand: ebmpapst

Description
Reviews (0)

Description

The ebmpapst G2E120-AR77-01 is a high-performance AC Centrifugal Fan with housing dimensions of 184 x 178 x 115 mm. It operates on 230 V AC, 50/60 Hz, single-phase power. It delivers a maximum airflow of 260 m³/h at 50 Hz and is designed for applications requiring consistent air movement against significant system back-pressure, such as in ducted ventilation systems, compact air conditioning units, and industrial control cabinets.

G2E120-AR77-01 Fan Parameters
Model: G2E120-AR77-01
Manufacturer: ebmpapst
Type: AC Centrifugal Fan (Single Inlet, Forward Curved Impeller)
Motor Model: M2E052-CF (Typical for this series)
Dimensions (Unit WHD): 184 x 178 x 115 mm
Nominal Voltage: 230 VAC
Phase: 1~ (Single-phase)
Frequency: 50/60 Hz

PERFORMANCE AT 230 VAC, 50 Hz
Speed: 2350 RPM
Power Consumption: 40 W
Current Draw: 0.17 A
Max. Airflow (Free Air): 260 m³/h
Max. Static Pressure: 150 Pa (0.60 inAq)

PERFORMANCE AT 230 VAC, 60 Hz
Speed: 2650 RPM
Power Consumption: 58 W
Current Draw: 0.25 A
Max. Static Pressure: 195 Pa (0.78 inAq)

Weight: 1.8 kg
Housing Material: Sheet metal, galvanized
Impeller Material: Sheet metal, galvanized
Bearing Type: Ball Bearing
Motor Design: External Rotor Motor, Capacitor Start
Motor Capacitor: 1.5 µF, 400 VDB
Motor Protection: Thermal Overload Protector (TOP) internally connected
Termination: Terminal Block
Insulation Class: B
Service Life L10 at 40 °C: 40000 h
Min. Ambient Temperature: -25 °C
Max. Ambient Temperature: 70 °C
Approvals: VDE, UL, CSA, CE, EAC
IP Rating: IP44
Protection Class: I
ApplicationThe ebmpapst G2E120-AR77-01 Centrifugal Fan is utilized in systems where reliable air movement against high resistance is critical. Its robust external rotor motor design and forward-curved impeller make it ideal for integration into compact air handlers, heat exchangers, small cleanroom modules, and ducted ventilation equipment requiring sustained high static pressure capability.

Brand new original imported fan G2E120-AR77-01 ebmpapst turbo cooling fan. Centrifugal fan. Imported fans. Germany EBM-papst

G2E120-AR77-01 ebmpapst turbo Centrifugal fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
