KAKU KA1806HA2 220~240V AC IP55 180x180x65mm Axial Fan

KAKU KA1806HA2 220~240V AC IP55 180x180x65mm Axial Fan

Name: KAKU KA1806HA2 220~240V AC IP55 180x180x65mm Axial Fan
Brand: KAKU
SKU: 1600283893854
Availability: InStock
Rating: 5 (4 reviews)

$34.00

SKU: 1600283893854 Brand: KAKU

Description
Reviews (0)

Description

The KAKU KA1806HA2 is a high-performance industrial axial fan engineered for continuous thermal regulation in demanding electrical environments. This unit utilizes Original Engineering standards to ensure seamless Technical Compatibility with standard 180mm cabinet cutouts. The dual ball bearing system provides extended lifecycle reliability compared to sleeve alternatives, making it a critical component for reducing downtime in power distribution units and CNC control cabinets.

Technical Specifications:
Manufacturer: KAKU
Model Number: KA1806HA2
Frame Dimensions: 180 x 180 x 65 mm
Input Voltage: 220-240V AC
Frequency: 50/60 Hz
Rated Power: 70/69 W
Rated Current: 0.59/0.52 A
Rotational Speed: 2600 RPM
Airflow: 380 CFM (645 m³/h)
Noise Level: 60 dBA
Bearing Type: Precision Dual Ball Bearing
Ingress Protection: IP55 (Dust and Water Jet Resistant)
Frame Material: Die-cast Aluminum Alloy with Black Coating
Impeller Material: PBT Thermoplastic (UL 94V-0 Rated)
Insulation Resistance: 100M Ω at 500V DC
Dielectric Strength: 1500V AC per minute
Operating Temperature: -20°C to +70°C
Storage Temperature: -40°C to +80°C
Weight: 1450g
Service Life: 50,000 hours at 25°C
Safety Compliance: CE, TUV, RoHS

Industrial Application:
The KA1806HA2 is specifically designed for high-heat density scenarios such as frequency converter cooling, large-scale server enclosures, and industrial automation panels. Its IP55 rating ensures operational stability in environments prone to dust and moisture ingress, solving the problem of premature component failure due to thermal throttling or environmental contamination. Optimized Lead Time ensures rapid deployment for critical infrastructure maintenance.

Key Attributes
Voltage: 220-240V
Mounting type: Free Standing
Type: Axial Cooling Fan
Warranty: 1 Year
Power Source: Electric
Blade material: Plastic
Bearing type: Ball Bearing
Customized support: OEM
After-sales service provided: Online support
Place of origin: China
Brand name: KAKU
Model number: KA1806HA2
Type: Axial Cooling fan
Current: 0.59/0.52A
Frequency: 50/60 Hz
Size: 180*180*65mm
Rated voltage: 220-240V
Power: 70/69W
Speed: 2600RPM
Air flow: 380CFM
Noise: 60dBA
Weight: 1450g

Packaging and Delivery
Selling Units: Single item

KAKU KA1806HA2 220~240V AC IP55 180x180x65mm Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
