MEIXING GX12025 110-240VAC 120x120x25mm 4Inch Axial Fan

MEIXING GX12025 110-240VAC 120x120x25mm 4Inch Axial Fan

Name: MEIXING GX12025 110-240VAC 120x120x25mm 4Inch Axial Fan
Brand: MEIXING
SKU: 1600950222088
Availability: InStock
Rating: 5 (4 reviews)

$2.08

SKU: 1600950222088 Brand: MEIXING

Description
Reviews (0)

Description

The MEIXING GX12025EC is a high-performance EC (Electronically Commutated) axial cooling fan engineered for demanding industrial and commercial thermal management. Utilizing advanced EC technology, this model offers significant energy savings compared to traditional AC fans, consuming only 6W while delivering a consistent rotational speed of 3200 RPM. The integrated driver supports a universal wide-range input of 110 – 240 VAC, ensuring seamless global compatibility across different power grids without the need for additional transformers.

Constructed with a precision double ball bearing system, the GX12025EC is designed for longevity and continuous operation in various orientations. The 120 x 120 x 25 mm frame is optimized for high-density airflow, making it an essential component for maintaining optimal operating temperatures in sensitive electronics. With a noise rating of 46 dBA, it balances high-velocity cooling with acoustic control, suitable for both industrial floors and office-adjacent equipment rooms.

Industrial Applications:
This axial fan is critical for heat dissipation in server racks, telecommunications enclosures, industrial control panels, and remote control systems. Its robust design and wide voltage tolerance make it a reliable choice for Original Engineering specifications and high-standard maintenance requirements.

Technical Specifications:
Brand: MEIXING
Model Number: GX12025EC
Fan Type: EC Axial Flow
Dimensions: 120 x 120 x 25 mm
Voltage Range: 110 – 240 VAC
Power Consumption: 6W
Rated Current: 0.07A
Rotational Speed: 3200 RPM
Noise Level: 46 dBA
Bearing Type: Double Ball Bearing
Blade Material: Reinforced Plastic
Mounting Type: Free Standing / Internal Mount
Weight: 0.500 kg
Service Life: High-Durability Industrial Grade

Key Attributes
Voltage: 110-240V
Speed: 3200RPM
Mounting type: Free Standing
Type: Axial Fan
Warranty: 1 Year
Power Source: Electric
Blade material: Plastic
Bearing type: Ball Bearing
Customized support: OEM, ODM
After-sales service provided: Online support
Place of origin: Zhejiang, China
Brand name: MEIXING
Model number: GX12025EC
Product name: EC Axial Flow Fan
Model: GX12025EC
Size: 120x120x25mm
Color: Black
Bearing Type: Ball
Power: 6W
Current: 0.07A
Voltage: 110-240V
Speed: 3200RPM
Noise: 46dBA

Packaging and Delivery
Selling Units: Single item
Single package size: 15X15X5 cm
Single gross weight: 0.500 kg

MEIXING GX12025 110-240VAC 120x120x25mm 4Inch Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
