MF60252Vx-1000C-A99 SUNON fan 24V magnetic

Name: MF60252Vx-1000C-A99 SUNON fan 24V magnetic
Brand: SUNON
SKU: 909842903910
Availability: InStock
Rating: 5 (4 reviews)

$2.86

SKU: 909842903910 Brand: SUNON

Description
Reviews (0)

Description

The SUNON MF60252 VX-1000C-A99 is a high-performance DC axial fan utilizing proprietary Magnetic Levitation (MagLev) Vapo bearing technology. Designed for continuous operation in demanding thermal environments, this unit eliminates physical contact between the shaft and bearing, significantly reducing noise, vibration, and friction while extending operational lifespan. The 24V DC motor architecture delivers consistent torque with a power consumption of 2.04W, optimized for high static pressure applications. This component ensures Original Engineering integrity for precision cooling systems requiring long-term reliability.

Technical Specifications:
Manufacturer: Sunonwealth Electric Machine Industry Co., Ltd.
Series: MagLev MF Series
Model Number: MF60252 VX-1000C-A99
Rated Voltage: 24V DC
Operating Voltage Range: 12V – 27.6V DC
Power Consumption: 2.04 W
Rated Current: 0.085 A
Dimensions: 60 mm x 60 mm x 25 mm
Bearing Type: Vapo (Magnetic Levitation)
Rated Speed: 5200 RPM ± 15%
Airflow: 23.5 CFM (0.66 m³/min)
Static Pressure: 0.26 Inch-H2O
Noise Level: 32.5 dB(A)
Frame Material: Thermoplastic PBT (UL94V-0)
Impeller Material: Thermoplastic PBT (UL94V-0)
Operating Temperature: -10°C to +70°C
Life Expectancy: 70,000 Hours at 40°C
Termination: Lead Wire (UL1007, 26AWG)
Weight: 45 g
Safety Certifications: UL, CUR, TUV
Function: Auto Restart / Polarity Protection

Industrial Application:
This specific cooling unit is engineered for telecommunications server racks, network switches, and industrial automation control panels where high component density restricts natural airflow. The high static pressure capability of the MF60252 VX-1000C-A99 effectively overcomes impedance in tightly packed enclosures, ensuring critical heat dissipation for FPGA modules and power supply units. Its MagLev design prevents dust ingress and lubricant leakage, guaranteeing Technical Compatibility with clean-room manufacturing equipment and 24/7 surveillance systems. Contact us for current Lead Time and bulk procurement data.

MF60252Vx-1000C-A99 SUNON fan 24V magnetic

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
