New EBMPAPST 8314 fan

Name: New EBMPAPST 8314 fan
Brand: ebmpapst
SKU: 920984750452
Availability: InStock
Rating: 5 (4 reviews)

$28.57

SKU: 920984750452 Brand: ebmpapst

Description
Reviews (0)

Description

The ebmpapst 8314 is a high-performance DC axial fan engineered for precision thermal management in industrial electronics and power conversion systems. Manufactured in Germany, this component utilizes a robust glass-fiber reinforced plastic housing and impeller (PBTP), designed to withstand mechanical stress and thermal fluctuation. The unit features a precision ball bearing system, ensuring consistent rotational stability and an extended service life significantly superior to sleeve bearing alternatives. This specific model is optimized for 24V DC systems, delivering a high airflow-to-noise ratio suitable for continuous duty cycles in noise-sensitive or vibration-prone environments.

TECHNICAL SPECIFICATIONS:
Manufacturer: ebmpapst
Model Series: 8300
Model Number: 8314
Component Type: DC Axial Fan
Nominal Voltage: 24 V DC
Voltage Range: 12 V to 28 V DC
Power Consumption: 2.7 W
Nominal Speed: 3300 RPM
Air Flow: 54 m³/h (31.8 CFM)
Noise Level: 36 dB(A)
Dimensions: 80 mm x 80 mm x 32 mm
Bearing System: Ball Bearing
Housing Material: PBTP (Polybutylene Terephthalate)
Impeller Material: PA (Polyamide)
Operating Temperature Range: -20°C to +75°C
Service Life L10 (40°C): 70,000 hours
Weight: 0.170 kg
Direction of Rotation: Clockwise, viewed toward rotor
Connection: 2 single strands AWG 24, TR 64

INDUSTRIAL APPLICATION:
This fan is specifically calibrated for the cooling of frequency converters, variable frequency drives (VFDs), and compact server power supplies. In these applications, the 8314 solves the critical problem of heat dissipation within high-density enclosures where static pressure is required to force air through dense heat sink fins. Its compact 80mm footprint allows for integration into tight spatial envelopes without compromising air volume, effectively preventing thermal throttling of power semiconductors and ensuring system stability under load.

PROCUREMENT & COMPATIBILITY:
We supply Original Engineering components to guarantee adherence to the manufacturer’s strict quality and safety standards. This unit ensures full Technical Compatibility with existing 8300 series mounts, making it an ideal replacement for maintenance, repair, and operations (MRO) requirements. Please contact our team to confirm current Lead Time for bulk orders or to verify specific termination requirements for your assembly.

New EBMPAPST 8314 fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
