New KA1725-3000E0B fan AC220V KAKU

Name: New KA1725-3000E0B fan AC220V KAKU
Brand: KAKU
SKU: 911807866438
Availability: InStock
Rating: 5 (4 reviews)

$11.43

SKU: 911807866438 Brand: KAKU

Description
Reviews (0)

Description

The KAKU KA1725-3000E0B is a high-performance Electronically Commutated (EC) axial fan designed for critical thermal regulation in industrial chassis environments. This unit integrates Original Engineering standards to deliver superior airflow efficiency compared to traditional AC induction fans, reducing power consumption while maintaining high static pressure. The robust construction features a die-cast aluminum frame and UL94V-0 rated thermoplastic impeller, ensuring durability in harsh manufacturing conditions. Its EC motor architecture allows for direct 220V AC input while providing the longevity and speed stability associated with DC motors. This specific model is engineered for Technical Compatibility with standard 172mm mounting cutouts, facilitating immediate retrofit or OEM integration.

Technical Specifications:
Manufacturer: KAKU
Model Number: KA1725-3000E0B
Fan Type: EC Axial Flow
Dimensions: 172mm x 150mm x 51mm
Rated Voltage: 220V AC
Frequency: 50/60 Hz
Bearing Structure: Dual Ball Bearing
Frame Material: Black Die-Cast Aluminum Alloy
Blade Material: PBT Thermoplastic
Airflow Capacity: High Volume (approx. 350 m³/h)
Operating Temperature: -20°C to +70°C
Insulation Resistance: > 500MΩ at 500V DC
Dielectric Strength: 1500V AC for 1 minute
Life Expectancy: > 60,000 hours
Weight: 0.85 kg

Industrial Application:
This cooling unit is specifically deployed in high-load electrical control cabinets and server rack enclosures where heat density exceeds the capacity of standard AC fans. It effectively manages thermal loads for Variable Frequency Drives (VFDs) and UPS systems, preventing component failure due to overheating. Contact us to verify Lead Time and bulk availability.

New KA1725-3000E0B fan AC220V KAKU

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
