New NMB-MAT 5920FT-D5W-B60 fan 24V

Name: New NMB-MAT 5920FT-D5W-B60 fan 24V
Brand: NMB
SKU: 908089927804
Availability: InStock
Rating: 5 (4 reviews)

$54.00

SKU: 908089927804 Brand: NMB

Description
Reviews (0)

Description

The NMB-MAT 5920FT-D5W-B60 is a high-performance DC axial fan engineered by MinebeaMitsumi specifically for thermal management in high-density industrial electronics. This unit represents Original Engineering from Japan, designed to deliver the exceptional static pressure and airflow required for cooling large-scale frequency converters, server racks, and power inverters. With a substantial current rating of 4.8A, this model is classified as a high-velocity air mover, ensuring rapid heat dissipation in enclosed cabinets where standard cooling solutions fail. The robust construction features a die-cast aluminum frame to withstand vibration and harsh industrial environments.

Technical Specifications:
Manufacturer: NMB-MAT (MinebeaMitsumi)
Model Number: 5920FT-D5W-B60
Device Type: High-Performance DC Axial Fan
Frame Dimensions: 172 mm x 150 mm x 51 mm (Side Cut)
Nominal Voltage: 24 V DC
Current Rating: 4.8 A
Power Consumption: 115.2 W
Speed: High-Speed / High-Torque Configuration
Bearing System: Precision Dual Ball Bearing
Housing Material: Aluminum Die-Cast
Impeller Material: Reinforced Plastic (UL94V-0)
Airflow Direction: Exhaust over Struts
Operating Temperature Range: -10°C to +70°C
Life Expectancy: 100,000 hours (L10 at 25°C)
Termination: Lead Wire Interface

Industrial Application:
This specific cooling unit is critical for the maintenance of variable frequency drives (VFDs) and high-load power supplies where thermal runaway poses a risk to system logic. The 5920FT-D5W-B60 provides the necessary air volume to penetrate dense heatsink fins found in heavy-duty automation equipment and telecommunication base stations. Ensuring Technical Compatibility with existing 24V industrial circuits, this fan minimizes downtime during maintenance cycles. Its high-amperage design indicates a focus on maximum CFM output for critical cooling zones. Please verify the mounting hole pitch and voltage requirements prior to ordering to ensure immediate integration. Contact us for details regarding Lead Time on bulk orders or specific connector configurations.

New NMB-MAT 5920FT-D5W-B60 fan 24V

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
