SANYO 109S072UL 230V AC 120x120x38mm Cabinet Axial Fan

Name: SANYO 109S072UL 230V AC 120x120x38mm Cabinet Axial Fan
Brand: Sanyo Denki
SKU: 62508831065
Availability: InStock
Rating: 5 (4 reviews)

$12.50

SKU: 62508831065 Brand: Sanyo Denki

Description
Reviews (0)

Description

The Sanyo Denki 109S072UL is a high-performance AC axial fan engineered for industrial-grade thermal management. Manufactured in Japan, this 120 mm x 120 mm x 38 mm unit is a standard in server rack cooling, control cabinets, and power supply enclosures. It utilizes a dual ball bearing system to ensure long-term reliability and consistent performance under continuous operation. With a rated voltage of 200 – 240 VAC, it delivers a high airflow rate of up to 174 m³/h, making it critical for preventing heat-induced failure in sensitive electronic components. This original engineering solution provides a robust balance between static pressure and noise levels, suitable for 24/7 industrial duty cycles.

Technical Specifications:
Brand: Sanyo Denki
Model Number: 109S072UL
Frame Size: 120 x 120 x 38 mm
Input Voltage: 200 – 240 VAC
Frequency: 50/60 Hz
Rated Current: 0.11 / 0.09 A
Rated Input: 18 / 16 W
Rotational Speed: 2700 / 3100 RPM
Maximum Airflow: 148 / 174 m³/h
Sound Pressure Level: 42 / 45 dBA
Bearing Type: Dual Ball Bearing
Operating Temperature: -30 to +60 °C
Frame Material: Aluminum Die-cast
Impeller Material: Plastic (UL 94V-0)
Weight: 0.55 kg
Origin: Japan

Application Scenarios:
This axial fan is specifically designed for high-density industrial environments including telecommunications infrastructure, CNC machine control panels, and automated manufacturing cabinets where thermal stability is paramount. Its wide operating temperature range and high-speed rotation make it an essential component for maintaining the longevity of internal circuitry in harsh environments. Lead time and availability are optimized for MRO (Maintenance, Repair, and Operations) requirements.

Key Attributes
Voltage: 230V
Mounting type: Free Standing
Type: Axial Cooling Fan
Warranty: 1 Year
Power Source: Electric
Blade material: Plastic
Bearing type: Ball Bearing
Customized support: OEM
After-sales service provided: Online support
Place of origin: Japan
Brand name: SANYO fan
Model number: 109S072UL
Product name: 109S072UL
Size: 120x120x38mm
Voltage: 230V
Current: 0.11/0.09A
Power: 18/16W
Frequency: 50/60HZ
Type: Axial fan
Rated input: 18/16W
SPL: 42/45dBA
Operating temperature: -30~+60 Celsius

Packaging and Delivery
Selling Units: Single item
Single package size: 21X21X12 cm
Single gross weight: 1.000 kg

SANYO 109S072UL 230V AC 120x120x38mm Cabinet Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
