SJ1238HA2SAT SANJUN 220V AC 120X120X38mm 0.13A Axial Fan

SJ1238HA2SAT SANJUN 220V AC 120X120X38mm 0.13A Axial Fan

Name: SJ1238HA2SAT SANJUN 220V AC 120X120X38mm 0.13A Axial Fan
Brand: SANJUN
SKU: 62215167072
Availability: InStock
Rating: 5 (4 reviews)

$6.60

SKU: 62215167072 Brand: SANJUN

Description
Reviews (0)

Description

The SAN JUN SJ1238HA2SAT is a high-performance industrial axial cooling fan engineered for precision thermal management in high-density electronic enclosures and control cabinets. Utilizing a robust die-cast aluminum alloy frame and reinforced PBT thermoplastic blades, this unit delivers a consistent 84 CFM airflow at a rated speed of 2600 RPM. The 220V AC configuration is optimized for global industrial power standards, ensuring Technical Compatibility with standard electrical panels and automated machinery. This Original Engineering solution is designed for high-reliability environments where thermal stability is critical for component longevity.

Technical Specifications:
Manufacturer: SAN JUN
Model Number: SJ1238HA2SAT
Frame Dimensions: 120 x 120 x 38 mm
Rated Voltage: 220V AC
Frequency: 50/60 Hz
Input Power: 21W
Rated Current: 0.13A
Rotational Speed: 2600 RPM
Airflow Volume: 84 CFM
Static Pressure: 0.32 Inch-H2O
Noise Level: 45 dBA
Bearing Type: Sleeve Bearing
Frame Material: Die-cast Aluminum Alloy
Impeller Material: PBT Thermoplastic (UL94V-0)
Termination: Terminal Type
Insulation Resistance: 100MΩ at 500V DC
Dielectric Strength: 1500V AC for 1 minute
Operating Temperature: -10°C to +70°C
Weight: 520g
Mounting: Free Standing / Flange Mount
Certifications: CE, RoHS Compliant

Industrial Application:
The SJ1238HA2SAT is specifically designed for continuous duty cycles in server racks, CNC machine control boxes, and power supply units. Its high static pressure capability allows it to effectively overcome resistance from dust filters and densely packed internal components, preventing thermal throttling and extending the lifecycle of sensitive semiconductors. This component is a critical spare part for maintaining optimal operating temperatures in automated manufacturing environments, ensuring minimal Lead Time for maintenance and repair operations.

Key Attributes
Mounting: Free Standing
Voltage: 220V
Blade material: Plastic
After-sales Service Provided: Online support
Warranty: 1 Year
Customized support: OEM
Place of origin: Taiwan, China
Brand name: SAN JUN
Product name: SJ1238HA2SAT
Current: 0.13A
Voltage: 220V
Specifications: 120*120*38MM
Port: Tianjin port
Package: 40*40*25 for Carton
Power: 21W
Bearing type: Sleeve
NOISE: 45DBA
WEIGHT: 520g

Packaging and Delivery
Selling Units: Single item
Single package size: 21X21X12 cm
Single gross weight: 1.000 kg

SJ1238HA2SAT SANJUN 220V AC 120X120X38mm 0.13A Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
