Description
The SNDWAY SW-32A Optical Automatic Level is a high-precision surveying instrument engineered for rigorous outdoor construction and geodetic applications. This model features a 32X magnification optical system housed within a durable ABS casing, designed to withstand harsh field conditions while maintaining measurement integrity. The core mechanism utilizes a magnetic damping compensator, ensuring rapid line-of-sight stabilization even in environments with heavy machinery vibration. This Original Engineering design facilitates precise height transfer and angle measurement. The unit provides high-fidelity imaging with an erect image orientation, ensuring Technical Compatibility with standard surveying protocols and leveling staffs. Lead Time for project completion is optimized through the fast-settling compensator and clear optics, reducing setup and reading time on complex sites.
Manufacturer: SNDWAY
Model Reference: SW-32A
Device Type: Optical Automatic Level
Magnification: 32X
Objective Lens Aperture: 38mm
Compensator Type: Magnetic Damping X-Wire Suspension
Standard Deviation (1km Double Run): 1.5mm
Compensator Working Range: ±15′
Setting Accuracy: ±0.3″
Minimum Focusing Distance: 0.5m
Field of View: 1°20′
Image Orientation: Erect
Circular Vial Sensitivity: 8’/2mm
Horizontal Circle Graduation: 360°
Tripod Connection: 5/8 inch Thread
Housing Material: Industrial ABS Plastic
Ingress Protection: IP54
Operating Temperature Range: -20°C to +50°C
Gross Weight: 1.76 kg
Packaging Dimensions: 260 x 230 x 170 mm
Application Scenario:
Deployed primarily in civil infrastructure projects, the SW-32A is essential for foundation leveling, cut-and-fill excavation analysis, and drainage slope setting. Its high magnification allows for accurate reading of leveling staffs at extended distances, solving the problem of visibility in large-scale road construction or high-rise structural alignment where precise elevation control is mandatory despite ground vibrations.
Key Attributes
Accuracy: 0.01
Smart App: None
Place of origin: Guangdong, China
Material: Plastic cover
Brand name: SNDWAY
Customized support: OEM
Warranty: 1 year
Product Name: SNDWAY SW-32A Optical Automatic Engineering Survey Auto Level
Type: Self-leveling auto level
Usage: Outdoor Engineering
Keyword: Auto level
Magnification: 32X
Color: Yellow + White
Installation method: With tripod
Material: ABS Plastic cover
Packaging and Delivery
Selling Units: Single item
Single package size: 26X23X17 cm
Single gross weight: 1.760 kg
