Description
The SNDWAY SW-DS50 is a professional-grade laser distance meter integrating a high-precision electronic angle sensor for simultaneous distance and inclination measurement. Engineered for the global B2B market, this device facilitates complex surveying tasks through advanced computational logic, including automated Pythagorean calculations for indirect height and horizontal distance verification. The unit features a robust ABS housing with IP54 ingress protection, ensuring operational stability in dusty and damp industrial environments. Original Engineering standards dictate the optical alignment, providing a measurement accuracy of ±2mm across the full 50-meter range. The integrated electronic level offers superior precision compared to traditional bubble vials, enabling rapid leveling and angle quantification on the large backlit display.
Brand: SNDWAY
Model: SW-DS50
Measurement Range: 0.05m – 50m
Accuracy: ±2mm
Leveling Technology: Electronic Angle Sensor (Real-time)
Laser Class: Class II, 635nm, <1mW
Measurement Functions: Distance, Area, Volume, Pythagorean (Indirect), Continuous, Min/Max
Data Storage: 30 Sets
Display: Multi-line FSTN LCD with Backlight
Ingress Protection: IP54 (Dust and Splash Proof)
Housing Material: Industrial ABS Plastic
Power Supply: 2x 1.5V AAA Batteries
Battery Life: 8000 Measurements
Auto Cut-off: Laser 20s / Device 150s
Operating Temperature: 0°C to 40°C
Storage Temperature: -20°C to 60°C
Dimensions: 112mm x 50mm x 25mm
Weight: 175g (Gross)
Certification: CE, RoHS, FCC
Industrial Application
The SW-DS50 is specifically calibrated for HVAC system integration and structural glazing audits where direct line-of-sight measurement is obstructed. The electronic angle sensor allows technicians to determine the vertical height of inaccessible ductwork or facade elements by measuring the hypotenuse and angle from a safe ground position. This capability ensures Technical Compatibility with BIM data verification processes. We maintain strict inventory controls to minimize Lead Time for bulk procurement.
Key Attributes
Type: Handheld Laser Rangefinders
Place of origin: Guangdong, China
Ingress Protection: IP54
Material: ABS Plastic
Size: 112*50*25mm
Weight: 175g(with box
Model number: SW-DS50
Brand name: SNDWAY
Customized support: OEM
Warranty: 6 Month
Brand Name: SNDWAY
Feature 1: Larger Screen Display
Feature 2: Electronic angle distance meter
Level Type: Electric Level
Accuracy: 2mm
Auto power off: 150s
Battery life/times: 8000 Times
Certification: CE
Packaging and Delivery
Selling Units: Single item
Single package size: 20X13X10 cm
Single gross weight: 0.320 kg
