UPS5000-A-30KTTL Huawei 30kVA Online Double Conversion UPS

Description

The Huawei UPS5000-A-30KTTL is a high-performance Online Double Conversion UPS with dimensions of 264 x 800 x 500 mm. As a premier power protection solution, it delivers a robust 30kVA (30kW) capacity, maintaining an industry-leading output power factor of 1.0. This 3-phase system is engineered to support a versatile input voltage range of 380V/400/415V, ensuring zero transfer time and a pure sine wave output through its advanced digital signal processing (DSP) technology.

Designed for maximum flexibility, the UPS5000-A-30KTTL features a unique 5U rack/tower convertible architecture, allowing it to be seamlessly integrated into standard 19-inch IT cabinets or deployed as a standalone tower unit. This model is exceptionally well-suited for mission-critical infrastructures, including small to medium-sized data centers, telecom switch rooms, financial branch offices, and precision laboratory environments where power reliability is paramount. With its high efficiency of up to 95.7%, it significantly reduces operational costs and carbon footprints, making it a sustainable choice for modern enterprises.

UPS5000-A-30KTTL Parameters

• • Manufacturer: Huawei
  • Model Number: UPS5000-A-30KTTL
  • UPS Type: Online Double Conversion (AC-DC-AC)
  • Rated Capacity: 30kVA / 30kW
  • Output Power Factor: 1.0
  • System Efficiency: 95.7% (Online Mode), Up to 99% (ECO Mode)
  • Operating Temperature: 0 – 40 ºC
  • Storage Temperature: -40 to 70 ºC
  • Relative Humidity: 0% – 95% (No condensing)
  • Operating Altitude: 0 – 1000 m (Derating required above 1000 m)
  • Audible Noise: ≤ 58 dB
  • Cooling Mode: Intelligent speed-controlled forced air cooling

Input Characteristics

• Input Wiring: 3Ph + N + PE
• Rated Voltage: 380Vac / 400Vac / 415Vac
• Input Voltage Range: 138 – 485 Vac (Full load at 305–485 Vac; linear derating at 138–305 Vac)
• Input Frequency Range: 40 – 70 Hz
• Input Power Factor: 0.99 (Full load)
• THDi: < 3% (Linear full load)

Output Characteristics

• Output Wiring: 3Ph + N + PE
• Output Voltage: 380Vac / 400Vac / 415Vac ± 1% (Static load)
• Output Frequency: 50/60 Hz (Synchronized with mains in normal mode)
• Frequency Stability: ± 0.05% (Battery mode)
• Overload Capacity: 110% for 60 min; 125% for 10 min; 150% for 1 min
• Waveform: Pure Sine Wave

Battery & Management

• Battery Voltage: 360 – 528 Vdc (Flexible 30 – 44 batteries; Default: 32)
• Charging Current: Max 15 A (Adjustable based on configuration)
• Communication Interfaces: RS485, FE, Dry Contacts (Supports SNMP/Modbus)
• Display: User-friendly LCD Control Panel

Physical Properties

• Overall Dimensions: 264 x 800 x 500 mm
• Form Factor: 5U Rack / Tower Convertible
• Net Weight: 70 kg
• Protection Level: IP20

Core Value & Features

• High Reliability: Features ultra-wide input voltage and frequency ranges to minimize battery discharge cycles, significantly extending battery service life even in harsh grid conditions.
• Compact Density: The 5U high-density design saves up to 50% of floor space compared to traditional tower UPS systems of similar capacity.
• Smart Management: Integrated intelligent monitoring allows for real-time tracking of power status and environment parameters via mobile or PC interfaces.
• Flexible Configuration: Supports self-adaptive battery strings, allowing the system to continue operation even if individual battery cells are removed during maintenance.
