W2E200-HK38-07 Ebmpapst 225x80mm 230V AC Axial Fan

W2E200-HK38-07 Ebmpapst 225x80mm 230V AC Axial Fan

Name: W2E200-HK38-07 Ebmpapst 225x80mm 230V AC Axial Fan
Brand: ebmpapst
SKU: 62039282722
Availability: InStock
Rating: 5 (4 reviews)

$64.00

SKU: 62039282722 Brand: ebmpapst

Description
Reviews (0)

Description

The Ebmpapst W2E200-HK38-07 is a high-performance AC axial fan engineered for mission-critical thermal management in industrial environments. Utilizing Original Engineering from Germany, this unit is optimized for continuous duty cycles within Rittal cabinet systems and high-capacity power inverters. The M2E068-CF motor architecture provides high-density airflow with exceptional Technical Compatibility for global 230V power grids.

Technical Specifications:
Brand: Ebmpapst
Model Number: W2E200-HK38-07
Motor Type: M2E068-CF
Nominal Voltage: 230 VAC
Frequency: 50/60 Hz
Power Consumption: 64 W
Current Draw: 0.29 A
Speed: 2550 RPM (50Hz) / 2800 RPM (60Hz)
Airflow: 544 CFM (925 m³/h)
Impeller Diameter: 200 mm
Frame Dimensions: 225 x 225 x 80 mm
Weight: 2.3 kg
Bearing Type: Maintenance-free Ball Bearing
Blade Material: Sheet steel, painted black
Housing Material: Die-cast aluminum
Direction of Rotation: Counter-clockwise viewed toward rotor
Degree of Protection: IP44
Insulation Class: F
Operating Temperature Range: -25 °C to +60 °C
Capacitor Requirement: 1.5 µF / 450 VDB
Certifications: CE, VDE, UL, CSA
Lead Time: Standard industrial availability applies

Application Scenario:
This axial fan is specifically utilized in high-load industrial scenarios such as Rittal TS8 enclosure cooling and variable frequency drive (VFD) ventilation. Its ability to maintain high static pressure makes it ideal for overcoming the internal resistance of air filters and densely populated component racks, preventing thermal throttling and extending the lifecycle of sensitive electronic components in harsh manufacturing environments.

Key Attributes
Voltage: 230v
Mounting type: Free Standing
Type: Axial Cooling Fan
Warranty: 1 Year
Power Source: Electric
Blade material: Sheet steel, painted black
Bearing type: Ball Bearing
Customized support: OEM
After-sales service provided: Online support
Place of origin: Germany
Brand name: Ebmpapst
Model number: W2E200-HK38-07
Product name: AC AXIAL FAN
Nominal voltage: 230V
Bearing Type: Ball Bearing
Power consumption: 64W
Air Flow: 544 CFM
Current: 0.29 (A)
Frequency: 50~60Hz
Size: 200 mm
Weight: 2.3kg

Packaging and Delivery
Selling Units: Single item

W2E200-HK38-07 Ebmpapst 225x80mm 230V AC Axial Fan

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Fans Maintenance and upkeep

1. The use environment should always be kept clean and tidy, the surface of the fan should be kept clean, there should be no sundries in the inlet and outlet air outlets, and the dust and other sundries in the fan and pipes should be cleaned regularly;

2. The fan can only operate under the condition that it is completely normal, and at the same time, it is necessary to ensure that the capacity of the power supply facilities is sufficient and the voltage is stable.

3. During the operation of the fan, if it is found that the fan has abnormal sound, the motor is seriously heated, the shell is live, the switch trips, and cannot be started, it should be stopped immediately for inspection. In order to ensure safety, maintenance is not allowed during the operation of the fan, and a test run should be carried out for about five minutes after the overhaul to confirm that there is no abnormal phenomenon before starting the operation;

4. The fan should be stored in a dry environment to avoid moisture on the motor. When the fan is stored in the open air, there should be defensive measures. In the process of storage and handling, the fan should be prevented from bumping to avoid damage to the fan.
